Copper Element 464

Price: $252.00 per pcs

Availability: Contact for availability — call (347) 262-9561 for lead time

Description

An OCS CE 464 copper convector element with brass headers: 4" nominal depth, 64" nominal length, rated at 46.5 square feet EDR - about 11,160 BTU/hr on steam at 240 BTU per square foot, or roughly 6,975 BTU/hr on hot water. One of the longest made, for large or heavily glazed rooms that would otherwise need two elements to meet the load. Copper carries heat away from the water faster than steel, so a copper element gives more output than a steel one of the same size - CE 464 is rated well above the equivalent SE 464. The tube is 1/2" ID, 5/8" OD copper with brass headers tapped 3/4" and a 1/4" plug; the element measures 3-3/4" deep and 2" high, and 63.75" end to end. Approximate weight 5.25 lb.
