Liberty PDC-115-2 Duplexcontrolpanel, 1PH, 115V, 25' Cord, 60Hz

Price: $794.25 per Pieces

Availability: Ships within 1-3 business days

Description

Liberty's PDC-115-2 is a PDC-Series duplex control panel. It monitors and alternates two pumps up to 1 HP / 12A each — a primary float switch calls one pump per cycle, alternating between them for even wear, and an alarm float switch signals a high-water condition and calls the second pump if the first fails. Individual manual-reset fuses protect each pump, plug-in receptacles accept standard or right-angle plugs, and a programmed 6-hour run limiter shuts the pump off if it runs dry or the water level doesn't drop. It has green power and pump-run indicators, an audible/visual alarm with a 9-volt battery backup, auxiliary contacts, and 20A resettable breakers. Wired for single-phase power at 115V, in a NEMA 1 indoor enclosure, with a 25' float switch cord.
