Liberty 1102/prg101m 1 HP Duplex Provore® Ejector Package, 1ph, 115v, 2" Discharge

Price: $4,365.00 per Pieces

Availability: Ships within 1-3 business days

Description

The 1102/PRG101M is a pre-assembled Liberty 1100-Series duplex sewage system, built around two 1 HP PRG-Series grinder pumps wired for single-phase power at 115V. It ships complete with discharge piping and floats in a structural-foam basin (30" diameter x 36" deep, 110-gallon capacity, 28-gallon pump-down volume per cycle), a 1/4" enamel-coated steel cover with molded torque-stops that hold both pumps in position, and a 4" inlet hub with rubber pipe seal. The cover carries a 2" discharge and vent flange, with two 16" pump access openings and a 10" inspection cover. Running two pumps in alternation gives it the redundancy multi-unit residential and commercial installations need if one pump fails or is pulled for service. An AE-Series control panel, sized to the pump's amperage, must be ordered separately — its floats come pre-mounted and pre-set from the factory once installed. Indoor installation only. PRG grinder models are available with 2" discharge only. Shipping weight approximately 291 lb.
